Cảm biến áp suất P7620A

SPECIFICATION

Performance characteristics:

• Accuracy at 25℃ (linearity, hysteresis, repeatability): ≦±0.5% F.S
• Stability at 25℃ ≦0.4% F.S./year
• Thermal Effect: ≦±0.04% F.S./ ℃

Environment characteristics:

• Media temperature range: -25… +85℃
• Ambient temperature range : 0… +70℃
• Storage temperature range : -25… +85℃
• Compensated range: -40… +135℃
• Weatherproof rating: IP 65

Physical characteristics:

• Housing: 304 stainless steel
• Fitting material: 304 stainless steel
• Ceramic Sensor: Aluminum Oxide Al2O3(96%)
• Seal Material: NBR
• Pressure Fitting (Connection): G ½ ”
• Electrical Connector: Terminal Box to DIN43650 A

Note: The wetted parts including fitting, sensor and sealing will be contacted with the media directly.

Electrical Data(Current):

• Output Signal: 4-20mA(2 Wire)
• Power Requirement: 10-32 VDC(Normal 24 VDC)
• Load Resistance: ≦(supply voltage-10V)/(0.02A) Ohms

Applications

• Industrial OEM equipments
• Hydraulic monitoring systems z
• Compressor controls
• Pneumatic systems
• Pump applications
• HVAC systems
